Substation Installation Services

We are GCC’s one of the best control system installation and E & I installation companies that provide the best substation installation services.

Nine main steps to building a substation are :

◾ Identify the work zone

◾ Substation site Prepare

◾ Excavate and lay the foundations

◾ Grounding grid installation

◾ Build the command building

◾ Backfill the foundations and substation yard

◾ Steel structures Assembling

Electrical equipment installation

◾ Landscape and carry out the final inspection


Above mentioned steps have to be done perfectly to lower the voltage generated by transmission lines, This is a major challenge you are going to face in each stage.

Testing / Commissioning And Condition Monitoring

LV/MV Switchgear

Promag TS specialized experts in the installation, testing, and commissioning of the LV/MV Switchgear. We have the best project managers, construction managers, QA/QC engineers, site engineers, HSE officers, and Store Keepers.

Switchgear installation procedure includes setting up safety requirements, work sequence and methodology, handling and storage, and general panel installation procedure.

◾ Complete plant electrical testing and commissioning including test like Tan delta, oil test and protection testing, Condition monitoring of electrical, mechanical, and instrument equipment.

◾ Partial discharge testing

◾ Vibration monitoring


Switchgear Commissioning & Maintenance

We will help you in all stages of the pre-commissioning process, from point wiring checks, function checks, and loop checks to the final handover of systems. We will help you to achieve individual requirements along with the option of choosing a preventive maintenance package designed and continued technical support for both electrical and instrumentation routines.

We undertake calibration and repair services within our laboratory; offering a complete electrical and mechanical calibration service along with switchgear testing and commissioning, switchgear maintenance and testing, installation, and providing scheduled items for 5-7 day laboratory turnaround times.

We have also proven our track record in delivering these services on-site as well.

◾ Installation, Commissioning & Maintenance of Instrumentation and Control Design.

◾ Installation, Maintenance & Inspection of Hazardous Area Instrument.

◾ Pipe Fitting Process & Pneumatic (impulse lines, air headers, control valves, SOVs, analyzers, etc,.)

◾ Designing and Building of Control Panel

◾ Calibration & Repair and Loop check

◾ Fiber Optic Networks

◾ Pneumatic Systems

◾ AutoCAD Designs


Electrical Inspection And Testing

While we do electrical substation installation services, we are backed with expertise in all types of electrical testing such as switchgear testing, substation testing, and even periodic inspection of electrical systems.

◾ Electrical Substation

◾ Electrical Designing, Installation Commissioning & Maintenance (Single 230V & three phase 400V)

◾ Installation, Maintenance & Inspection of Hazardous Area Electrical

◾ Installations of Small Power and Lighting

◾ Distribution of LV Power

◾ Installations and Relocation of Production Line and Machinery

◾ Containment process (tray, ladder rack, basket tray, trunking, conduit, dado rail, etc.)

◾ Sizing, Procurement & Installation of Cable

◾ Glanding and Termination of Cable

◾ Designing & Building of Control Panel

◾ Inspection and Testing on a periodic basis

◾ Network & Data Cabling


Reach Us

With a decade of experience, right project team and plethora of delighted clients – Promag have
proved to be a committed partner for large scale projects.
